Sold Out $260.00
Electroswitch® Oak Grigsby 4 Pole Double Wafer Blade "Super" Switch 5 Position
Electroswitch® Oak Grigsby 4 pole blade switch. 5 position for Fender® Stratocaster or similar applications.
The new improved Super Switch lets you wire guitars in imaginative ways not possible with our other 5-way switches. It's a special 4-pole switch with six lugs per pole (one common and one each for the five lever positions. This gives you unparalleled control over pickup and coil selection.
Terminal assignment: There are a total of 24 solder terminals (lugs) on this switch. The switch is divided into four separate circuits, or poles, and each pole has six lugs. Lug 0 is the common which is connected to other lugs depending on the lever's position. The five other terminals on each pole correspond to the five positions of the switch. Lug #1 = position 1, Lug #2 = position 2, etc.
Many lever switches use the commons as outputs for the switch, but with this switch this is not necessarily going to be the case. The commons of this switch can be used to connect pickups together in ways not possible with other switches. This is an important concept to understand when designing custom wiring for this switch.
(Switch Tip NOT included)
** Shipping Cost to Hong Kong and Macau will be charged by SF Express (Pay by receiver)
$450.00
All you need to adjust your gear 12 Allen key sizes: .050", 1/16", 5/64", 3/32", 7/64", 5/32", 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm, 5.0mm 3 Phillips: #0, #1, #2 3 Flat...
$100.00
Specifications: Diameter: 24mm (0.94") Height: 14.5mm (0.57") Insert hole: 11.2mm (0.44") Material: Aluminum Color: Natural Aluminum Weight: 10gr (0.02lb) Kit mounting Made in Italy ** Shipping Cost to Hong Kong...
$150.00
Specifications: Diameter: 28.5mm (1.12") Height: 20.5mm (0.80") Insert hole: 11.2mm (0.44") Material: Aluminum Color: Luminor Weight: 22gr (0.04lb) Kit mounting Made in Italy ** Shipping Cost to Hong Kong and...
